High Security PAS68 Fixed and Removable Bollards

AS RATED TO PAS68

Bristorm Impeder Bollards are the highest security steel bollards available in the UK. Tested to BSI PAS68 or IWA 14-1, Bristorm Impeder bollards offer 3 levels of performance, thus allowing you to mitigate the vehicular threat perceived in that specific location. Bristorm Impeder bollards are manufactured from High Grade Steel, cast into concrete foundations. They can be installed in small arrays or as a complete perimeter line to ensure hostile vehicles, travelling at 30, 40 or 50mph, are mitigated.

Product Features: Tested to BSI PAS 68 or IWA 14-1

  • Economical option for short lengths of perimeter
  • Can integrate with other Bristorm products
  • Shallow mount versions available, ~300mm
  • 219mm(30mph), 273mm(40 & 50mph) diameter for rated products
  • Typical 1200mm clear spans for all rated products
  • Typically immobilizes attacking vehicle
  • Ability to withstand subsequent encroachment
  • Certain models available as removable
  • Under 1m penetration version available
  • All galvanised as standard – EN ISO 1461:2009
  • Bollard height – 1000mm above finish level
  • Accommodation for up to 100mm ground finish thickness
  • Stainless steel or powder coat finishes available

-see Bristorm Street Furniture

Bristorm Impeder Bollard Ratings:

All bollards tested as a single bollard, in standard minimum footing.

Impeder 30 – 30 mph (48kph) – Impacted tested to PAS68:2010 => V/7500[N2]/48/90:0.0/0.0

Impeder 30 Shallow – 30 mph (48kph) – Impacted tested to IWA 14-1:2013 => V/7500[N2]/48/90:0.0/0.0

Impeder 40 – 40mph (64kph) – Impacted tested to PAS68:2010 => V/7500[N2]/64/90:3.3/0.0

Impeder 50 – 50mph (80kph) – Impacted tested to PAS68:2010 => V/7500[N2]/80/90:2.0/12.0

Impeder 50 Shallow – 50mph (80kph) – Impacted tested to IWA 14-1:2013 => V/7500[N2A]/80/90:3.0/x.x
